Sump design help? TOTW 10-21-05

Hi all,

I have been playing around with a sump design to go under my 75 gallon tank. Does the following design seem okay? Have I overdone it with the baffles? I have been trying to read up on this. I am no plumber, but eager to give it a shot. Any tips or suggestions from those who have done this before would be much appreciated!! I suspect I am forgetting about or not planning for something obvious!

http://www.reefland.com/forum/attach...1&d=1128649309

Thanks in advance for your thoughts!

-Jason
Attached Thumbnails
__________________
Help! Do they make a saltwater patch? I think I’m addicted!
Fish R.Ph. is offline   Reply With Quote
Sponsored Links

Old 10-06-2005, 10:19 PM   #2
#99
sponsor

#99's Avatar

Join Date: Jul 2005
Location: Arizona
Posts: 30
Just a little overkill with the baffles.My opinion I would get rid of 2,3,4,5.
__________________
Disasters happen quikly,success takes time and patience.
---------------------------------------------------
my online store http://allaquatics.net
#99 is offline   Reply With Quote
Old 10-09-2005, 11:26 AM   #3
Moderator

Poseidon's Avatar

Join Date: Sep 2001
Location: Swartz Creek, MI
Posts: 6,261
Send a message via AIM to Poseidon
Hey Jason, I run my sump with only 2 baffles. It would be #6, and 7 on your drawing. I don't have any problems with bubbles either. My sump is a 30 gallon long, so there is not that much space, but as long as I keep the sump level up, I don't have any problems. PLUS when the water gets low, it is the last chamber that has a water level drop, which causes the return pump to blow bubbles... A good reminder that it is time to add water!
__________________
Need a Photographer?

Just say NO to CRABS

Mike
Poseidon is online now   Reply With Quote
Old 10-09-2005, 02:34 PM   #4
Owner

Join Date: Feb 2000
Location: Bardstown, KY
Posts: 13,031
Lots of different options here. I would remove 1,2,3 and put 4 where 1 is (increasing the size of your refuge space).
__________________
Scott Z.
75 Gallon Reef Log
Powered by Reefland's Personal Online Aquarium Log
Reefland is offline   Reply With Quote
Old 10-09-2005, 10:00 PM   #5
Citizen

Join Date: Apr 2005
Location: Whitinsville, MA
Posts: 130
Send a message via AIM to Fish R.Ph.
Revised Plan & more questions...

Quote:
Originally Posted by Reefland
Lots of different options here. I would remove 1,2,3 and put 4 where 1 is (increasing the size of your refuge space).
Okay,

Obviously I was over-freakining about bubbles with all those baffles.

Here is the "back to earth" plan:

http://www.reefland.com/forum/attach...1&d=1128908803

Now.....I just have a few more dumb questions from a sump simpleton:

1) How far down into the sump should downspout from the display tank go? I mean, should you bring the PVC down to the bottom of the sump and end with an elbow? Or should it be closer to the top of the water line?

2) What is the advantage of PVC over flexible tubing for the plumbing both to and from the sump?

3) Would it be best to "T" off the return plumbing and have two "U" pipes at opposite ends of the main tank to improve ciculation? Maybe at different depths?

4) Is the noise from a Mag 9.5 much greater than a Mag 7? If not, should I just go for the 9.5 instead???

Any other tips to avoid a major flood?

Thanks for the input from all of you!
-Jason
Attached Thumbnails
__________________
Help! Do they make a saltwater patch? I think I’m addicted!
Fish R.Ph. is offline   Reply With Quote
Old 10-16-2005, 01:23 PM   #6
Moderator

The R/C Man's Avatar

Join Date: Aug 2004
Location: Spokane WA
Posts: 704
Send a message via ICQ to The R/C Man
I didn't read the whole post but be sure you have enough room in the sump to allow for the water from the main tank during a power outage.
__________________
Greg

25 gallon reef with 20 gallon sump/fuge
375 gallon reef with 100 gallon sump/fuge: under construction


Over time science has shown that the simplest answers are usually the correct ones.......
The R/C Man is online now   Reply With Quote
Old 10-21-2005, 09:35 AM   #7
Moderator

scubadude's Avatar

Join Date: Nov 2000
Location: Wichita, Kansas
Posts: 5,293
Excellent now not only will the sump be easier to construct as well as cheaper. You now have more room in your sump for other things like equipment, or even a refugium. Great thread guys!
__________________
Rocky

scubadude is offline   Reply With Quote
Old 10-21-2005, 07:17 PM   #8
Moderator

The R/C Man's Avatar

Join Date: Aug 2004
Location: Spokane WA
Posts: 704
Send a message via ICQ to The R/C Man
The design is very similar to my small sump and the sump/fuge for the 375... I always believe that keeping it simple is the way to go.

I have seen some really elaborate designs and I can't help but wonder how someone could possible "baby sit" that tank. If something where to go wrong....... Oooooohh.....
__________________
Greg

25 gallon reef with 20 gallon sump/fuge
375 gallon reef with 100 gallon sump/fuge: under construction


Over time science has shown that the simplest answers are usually the correct ones.......
The R/C Man is online now   Reply With Quote
Old 10-21-2005, 07:41 PM   #9
Moderator

scubadude's Avatar

Join Date: Nov 2000
Location: Wichita, Kansas
Posts: 5,293
yet another thread that is on sump baffles

TOTW 04/04/05 Sump baffles.......

and heres one involving water level/topoff control via the sump.

TOTW 4-19-05 sump water levels

As long as every function you can think of is incorporated in the sump then only build it for what it needs to be.
__________________
Rocky

scubadude is offline   Reply With Quote
Old 10-22-2005, 09:11 AM   #10
Citizen

Join Date: Apr 2005
Location: Whitinsville, MA
Posts: 130
Send a message via AIM to Fish R.Ph.
Quote:
Originally Posted by scubadude
Excellent now not only will the sump be easier to construct as well as cheaper. You now have more room in your sump for other things like equipment, or even a refugium. Great thread guys!
Just another "Thanks" for all the help and input on the sump design. Here is a sketch of the final plan I used:



Here is a live shot of the installed baffles (pardon the lousy silicone job... )
